  3. Purelux Black Boost S560 Gen3 Led Lightbar - Straight / 56 cm / 200W / Ref. 50
By Purelux

Purelux Black Boost S560 Gen3 Led Lightbar - Straight / 56 cm / 200W / Ref. 50

€185,00
€185,00
Tax included. Shipping calculated at checkout.
Brand: Purelux
Availability: Low stock: 10 left
SKU: PURELUXS560
€185,00
€185,00

The Purelux Black Boost S560 Gen3 is a high-performance auxiliary light from the Black series, offering top-quality features at an affordable price. It boasts two power modes: a road-legal mode with 5954 lumens and the powerful off-road PowerBoost® mode with up to 12648 lumens and a range of 654 meters. Its updated design includes a dynamic dual-colour parking light (orange/white) and an easier switching system for power modes. The S560 Gen3’s beam is optimized for road traffic, combining a bright central spot for long-range visibility with lateral illumination, while its curved model provides a wider horizontal beam. The 5700 Kelvin colour temperature and frameless lens design prevent snow, ice, and dirt build up. Constructed with a powder-coated aluminium alloy frame and polycarbonate lens, it is IP69K-rated for water and dust protection. Installation is simple with the DTP-2 connector, adjustable mounting options, and compatibility with 12V and 24V systems. Stylish, durable, and user-friendly, the S560 Gen3 is ideal for a variety of vehicle installations.

Key Features:

  • Application: Additional lighting for cars, off-road vehicles, and work machines
  • LED Type: Osram
  • Operating Voltage: 9-32 V
  • Reference Number: 50
  • Power:
    • Purelux PowerBoost®: 200 W (14.65A @ 12V / 7.33A @ 24V)
    • Road Mode: 83.9 W (6.99A @ 12V / 3.49A @ 24V)
  • Light Output:
    • Manufacturer Declared: 16800 lm (Purelux PowerBoost®)
    • Measured: 12648 lm (Purelux PowerBoost®), 5954 lm (Road mode)
  • Range:
    • Purelux PowerBoost®: 654 m @ 1 lux / 1090 m @ 0.25 lux
    • Road Mode: 410 m @ 1 lux / 820 m @ 0.25 lux
  • Colour Temperature:
    • Declared: 5700 K
    • Measured: 5840 K
  • Mounting: End legs or adjustable lower legs
  • Connector: DTP-2
  • Parking Lights: Separate wires
  • Cable Length: 50 cm
  • Dimensions: 561 x 70 x 67 mm (Width x Height x Depth)
  • Height: 86 mm (end legs) / 89 mm (lower legs)
  • Weight: 2300 g
  • IP Rating: IP69K
  • Approvals: ECE R10, R148, R149* (*PowerBoost® mode not road traffic approved)

Standard Package:

  • Purelux Black Boost S560 Gen3
  • 2 x Levees with adjustable footrests
  • 2 x Headrests
  • Power cable connector
  • Connection and installation instructions (EN/SE/NO/DK/FI)
